General Specifications
| Part No. | NR01105ANG13 |
|---|---|
| Description | Subminiature Process Sealed Rotary Switches |
| Name | ROTARY SWITCHES |
| Series | NR01 |
| Circuits | On-On-On-On-On |
| Current Rating | 0.4VA (AC/DC) |
| Rating | 0.4 | Illumination | Non-Illuminated |
| Mounting Type | Through Hole |
| Keywords | Positive, Distinctive Detent |
| Contact Finish | Gold Plating |
| Rating (AC) | 28V |
| Rating (DC) | 28V |
| No Positions | 5 |
| Actuator Type | Shaft |
| Termination Style | Straight PC Terminals with Bracket |
